About 70.4067 Dual Wheel Kit
Dual Wheels are available for the 4520 and 4500 tractors. They are designed to increase stability, traction, and safety on slopes. Dual wheels are also great for reduction of soil compaction on delicate ground. Once the dual hubs have been installed on each wheel, the duals can be quickly mounted and dismounted. Duals are recommended for sandy soils or where a broad distribution of tractor weight is desired, including when driving sideways on slopes greater than 20 degrees (not to exceed 30 degrees).Duals are only one of numerous considerations for safety on slopes; speed, terrain, irregularities, and stopping the unit are other serious factors to consider for safe operation of the tractor.NOTES:
- Do NOT use dual wheels when using the Ventrac VERSA-Loader.
- Engine manufacturers' maximum angle of operation is 250 for continuous use (all directions) and 300 intermittent use*.
- Do NOT use with Wheel Extensions
* Intermittent use is up to 10 minutes on the slope, then return to level ground before returning to the slope.
Exceeding the rated angle of operation may result in engine damage.
Base Specifications
Info
Dimensions
Weight
80 lbs per axle
80 lbs per axle
80 lbs per axle
General
Tire Type
All Terrain Standard
Turf
Bar
Additional Tractor Width
24 in (12"/Tire)
24 in (12"/Tire)
24 in (12"/Tire)
Width with Single Tires
48 in
49 in
47 in
Width with Dual Tires
70 in
72 in
68 in
Accessories for 70.4067 Dual Wheel Kit
-
70.4140 KIT, SLOPE INDICATOR
Videos
Ventrac 4500 Dual Wheel Installation & Removal
Video guide on how to properly install and remove a Dual wheel kit.
Learn More
