Product Overview

The KP540 Power Rake is designed for leveling rough ground and new yard installations, as well as removing surface rocks and debris. Its compact design allows the operator to work in tight quarters including around corners and edges.

Seventy-two replaceable carbide tips pulverize and refine the soil. Materials can be moved forward or to either side by hydraulically angling the drum left or right. The drum can also be reversed to allow back-dragging of soils. A rotating handle adjusts the height by up to 3 inches in ⅛ increments.

Adjustable side wings can be lowered on both sides for routing material.

MODELS

KP540 POWER RAKE 39.55435

PRODUCT BENEFITS

Bring New Life To Your Driveway

The KP540 Power Rake is designed for leveling roughground and new yard installations, as well as removingsurface rocks and debris.
Works In Both Directions

The drum can also be reversed to allow back-dragging of soils and cleaning off debris.
Quickly Prepare New Lawn Installation
Ventrac Mount System

With a little practice, you can switch almost any attachment within a minute, without any tools or heavy lifting.

RESOURCES

Compact Tractor Solution

Mark Workman discusses how he uses Ventrac compact tractors and the power rake attachment for seed bed preparation in areas too small to fit conventional tractors and skid loaders.
Repair Playground Mulch with Ventrac Power Rake

The Ventrac Power Rake is an excellant tool for Schools that are concerned with trying to keep their playgrounds safe by keeping a level, safe playing surface.
YMCA Seedbed Preparation

Two experienced operators use the Power Rake and Landscape Rake to prepare for seeding by by removing rocks, leveling ground and smoothing dirt.
Horse Arena Transformation

This horse owner did not want to resort to using chemical weed killers on their riding arena, but the weeds had taken over and the sand has become compacted, making an unsightly mess of the riding area.
Power Rake Advantage

Discover the Power Rake difference.
Simple Start - Operations Overview for the Ventrac KP540 Power Rake

The Ventrac Power Rake is an excellent tool for finish-grading or renovation work on dirt or gravel surfaces. Leveling rough ground, new yard installation and removing surface rocks and debris are just a few of the jobs this machine does well.
How to Install a New Lawn with One Tractor

In this video, you will see how we used one 4500 tractor and six different attachments. This is a great example of how a Ventrac can make projects that usually require several purpose-built machines, into an efficient and productive experience, all while illustrating Ventrac's versatility!
Repairing a Gravel Driveway with the Ventrac Power Rake

kp540 SPECIFICATIONS

Measurement System:
Standard

Metric

Specifications	39.55435
Info
Sales Model	KP540
Full Description	KP, KP540 Power Rake
Product Type	Attachment
Category
Front Mount	Ventrac Mount System
4000 Series Mount
Dimensions
Length	59 in
Overall Height	36 in
Overall Width	63 in
Weight	536 lbs
Length with Handle	70¹⁄₂ in to 75"
General
Rotor Width	54 in
Carbide Tips	72
Height Adj	3¹⁄₂ in range
Power Angle	18 deg
