Product Overview
Ventrac Snow Blowers are built for commercial snow clearing operations of sidewalks, driveways, and other areas. Available in width options of 48" and 52", these two stage snow blowers feature a 16" diameter solid auger for best snow transfer, a large 20" diameter fan, and the ability to launch snow at distances up to 40 feet.
Standard features include adjustable cast iron skid shoe discs at the rear, high carbon hardened steel shoes at the side, and a reversible high carbon hardened steel cutting edge.
The hydraulically activated discharge chute can rotate 220 degrees, all from the convenience of the operator’s seat, using Ventrac's exclusive S.D.L.A. control system. Chute deflection is manually adjustable and an electric chute deflection controller is optional.
MODELS
KX480 48" SNOWBLOWER 39.55428
KX523 52" SNOWBLOWER 39.55427
ACCESSORY OPTIONS
70.8025 KIT, 12V ACTUATOR, HB/KX/LX
70.4104 KIT, 12V FRONT 4500
70.8219 KIT, DEEP SNOW KX480
70.8072 KIT, DEEP SNOW KX522, KX523
PRODUCT BENEFITS
-
Ventrac Mount System
With a little practice, you can switch almost any attachment within a minute, without any tools or heavy lifting. -
Extreme Snow Performance
Built to handle all snow conditions, from light snowfalls to winter's wrath. Ventrac gives you a peace of mind for easily clearing snow. -
Move Winter's Worst
Ventrac's two-stage snow blower is an industry leader, built for deep snow. Move up to 4500 lbs (KX523) or 2500 lbs (LX423) of snow per minute and throw snow distances up to 40 feet.
Removing Deep Snow From Sidewalks with the Ventrac Snow Blower
On this Ventrac In Action video shoot, we showcase the capabilities of our machine in extreme weather conditions. Extreme snow performance means the Ventrac tractor and its attachments are built to handle all snow conditions, from light snowfalls to winter's wrath.
Snow Blower in Action
See raw footage of the KX523 snow blower in action clearing off sidewalks, driveways, and parking lots.
Snow Management Solution
Landscape Industry Consultant, Phil Harwood, describes why Ventrac is an ideal power unit for Landscape Contractors looking to manage sidewalk snow.
100 Pumpkins vs Snowblower
What happens when 100 pumpkins go through a snowblower?
Operations and Overview for the KX523 Snow Blower
The KX523 Snow Blower is built for when the snow accumulation becomes deep and compacted on sidewalks, driveways and other areas.
Ventrac Superb for Ice Rink Perfection at Canada Hockey Championships
Ventrac equipment help clear a frozen pond for the Canadian National Pond Hockey Championships in Ontario, Canada.
Removing Deep Snow From Sidewalks with the Ventrac Snow Blower
Snow Blower in Action
Snow Management Solution
100 Pumpkins vs Snowblower
Operations and Overview for the KX523 Snow Blower
kx SPECIFICATIONS
| Specifications | 39.55427 | 39.55428 |
|---|---|---|
| Info | ||
| Picture |  |  |
| Sales Model | KX523 | KX480 |
| Full Description | KX, KX523 52" Snowblower | KX, KX480 48" Snowblower |
| Product Type | Attachment | Attachment |
| Category | ||
| Front Mount | Ventrac Mount System | Ventrac Mount System |
| 4000 Series Mount | | |
| Dimensions | ||
| Length | 49 in | 49 in |
| Overall Height | 561⁄2 in | 561⁄2 in |
| Width with Wings | 523⁄4 in | 483⁄4 in |
| Overall Width | 52 in | 48 in |
| Weight | 517 lbs | 490 lbs |
| Crated Weight | 625 lbs | |
| General | ||
| Overall Width | 52 in | 48 in |
| Snow Capacity | 4500 lbs/min | 4000 lbs/min |
| Blowing Distance | 35-40 ft Approx | 35-40 ft Approx |
| Chute Rotation | 180 ° | 180 ° |
| Cutting Height | 261⁄2 in (no aux. auger) | 261⁄2 in (no aux. auger) |
| Auger Diameter | 16 in | 16 in |
| Main Auger RPM | 197 RPM | 197 RPM |
| Fan Diameter | 191⁄2 in | 191⁄2 in |
| Directional Control | Hydraulic | Hydraulic |
| Fan RPM | 790 RPM | 790 RPM |
